Airtac MU Mini Free Mount Cylinder MU10X6
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X6 Technical Details
- Model: MU10X6
- Type: Single-acting spring return (Push type)
- Bore size: 10mm (±0.1mm tolerance)
- Stroke: 6mm (adjustable ±0.5mm)
- Operating pressure: 0.05–0.7 MPa
- Operating medium: Dry air (ISO8573-1:2010 Class 3.4.2)
- Cushioning: Rubber buffer + shock absorber pad
- Port size: M5x0.8 (DIN3852 Form E)
- Piston material: Aluminum alloy (AlSi10Mg) with hard anodizing
- Rod material: Stainless steel SUS304
- Seal material: NBR (Nitrile) standard / Optional FKM
- Temperature range: -20℃ to 80℃ (NBR) / -10℃ to 150℃ (FKM)
- Protection rating: IP54 (standard) / IP67 (optional wiper upgrade)
- Weight: 72g ±2g (without accessories)
- Dimensions: 56mm(L) × 20mm(W) × 20mm(H) (retracted position)
- Max theoretical force: 5.5N @0.5MPa
- Piston speed: 50–500mm/s (optimal range)
Ultra-compact cylinder with integrated mounting slots (front flange & side taps) for space-constrained automation. Features dual-layer chrome plating on piston rod for enhanced corrosion resistance. Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (1:1000 ratio recommended).
- PCB handling robots in electronics assembly
- Precision clamping in micro-milling machines
- Valve actuation in portable medical analyzers
- Paper feed mechanisms in POS printers
- Lens positioning systems in optical equipment
Installation guidelines:
Maintain 0.5mm clearance between rod end and load during alignment.
For vertical mounting, use model MU10X6-V with reinforced spring.
Lubricate every 50km stroke or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | MU10X6 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <6mm> |
