Airtac MU Mini Free Mount Cylinder MU10X6B
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X6B Technical Details
- Model: MU10X6B
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 6mm
- Operating pressure: 0.05–0.8 MPa (0.5–8 bar)
- Port thread: M5×0.8
- Piston speed: 50–700 mm/s
- Cushioning: Rubber buffer + adjustable cushion screw
- Mounting style: Free installation (no specific orientation required)
- Body material: Aluminum alloy (anodized surface)
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Ambient temperature: -20℃ to 80℃
- Weight: 85g ±2g
- Dimensions (L×W×H):
56mm (total length) × 28mm (mounting width) × 28mm (height)
*Stroke length not included in total length - Protection class: IP54 (standard), IP67 optional
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features dual-position sensing slots (magnetic switch ready) and corrosion-resistant construction. Requires 5μm filtered lubricated air (ISO 8573-1 class 4). Maximum lateral load capacity: 3N at full extension.
- PCB handling robots in electronics assembly
- Micro-dosing valves in medical devices
- Precision clamping mechanisms for watchmaking
- Compact sorting gates in packaging lines
- Laboratory automation sample handlers
Installation guidelines:
Maintain 0.5mm minimum clearance between magnetic switch and cylinder body.
For vertical mounting, use spring-side down orientation. Lubricate every
500,000 cycles with ISO VG32 turbine oil. Avoid side load exceeding 0.5N·m.
| Property | Property Value |
|---|---|
| sku | MU10X6B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <6mm> |
