Airtac MU Mini Free Mount Cylinder MU10X6S
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mounting Cylinder MU10X6S Specifications
- Model: MU10X6S
- Bore size: 10mm (0.39")
- Stroke: 6mm (0.24") ±0.5mm tolerance
- Operating pressure: 0.05–0.9 MPa (7–130 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5x0.8 (standard) with optional NPT1/8 adapter
- Cushioning type: Fixed rubber buffer + shock absorber pad
- Mounting style: Free installation (no specific bracket required)
- Piston rod material: Stainless steel SUS304
- Cylinder tube: Aluminum alloy with hard anodized finish
- Seal material: NBR (Nitrile) for standard use, optional FKM seals
- Weight: 85g ±3g (body only), 92g with all accessories
- Dimensions:
- Total length: 56mm (2.20") at mid-stroke
- Body diameter: Φ18mm (0.71")
- Mounting hole spacing: 25mm (0.98") center-to-center
- Rod end thread: M4x0.7 male thread
- Lubrication: Pre-lubricated (DOP-free grease), maintenance-free for 2000km operation
- ISO certification: Complies with ISO 6432 standard
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features dual-action operation with 0.5mm/s minimum controllable speed and ≤0.15MPa starting pressure. The anodized body resists chemical corrosion in humid environments (up to 95% RH non-condensing). Includes built-in magnetic sensor slots for position feedback compatibility.
- PCB handling robots in electronics manufacturing
- Precision valve actuation in medical analyzers
- Label application mechanisms in packaging lines
- Camera shutter controls in optical inspection systems
- Vending machine currency acceptors
Installation guidelines:
Maximum side load ≤3N. For vertical mounting, use speed controller (ASC-06) to prevent piston slam.
Lubricate rod every 500,000 cycles in high-cycle applications (>5Hz). Avoid direct exposure to cutting fluids.
| Property | Property Value |
|---|---|
| sku | MU10X6S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <6mm> |
