Airtac MU Mini Free Mount Cylinder MU10X8B
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU10X8B Compact Free Mount Cylinder Specifications
- Model: MU10X8B
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 8mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable air cushion
- Mounting style: Side-mounted with 4x M3 threaded holes
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber (oil & heat resistant)
- Weight: 0.12kg (excluding accessories)
- Dimensions: 52mm(L) × 20mm(W) × 20mm(H)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (DOP-free grease)
Ultra-compact cylinder optimized for space-constrained automation systems. Features precision-ground rod and dual anti-rotation guides for smooth linear motion. The corrosion-resistant construction and IP54-rated wiper seal enable reliable operation in dusty environments. Requires 5μm filtered compressed air.
- PCB handling robots in electronics manufacturing
- Medical device component positioning
- Textile machine thread control mechanisms
- Semiconductor wafer processing equipment
- Automated test fixture actuation
Installation note:
Maintain 0.5mm clearance between rod end and load during alignment.
For vertical mounting, reduce operating pressure by 20% to compensate for spring force.
| Property | Property Value |
|---|---|
| sku | MU10X8B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <8mm> |
