Airtac MUR Compact Free Mount Cylinder MUR12X15
$23.23
Regular price
$30.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MUR12X15
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
Installation note:
For vertical mounting, use locknuts on both sides of mounting slot.
Maintain 0.5-1mm clearance between cylinder base and mounting surface
to prevent thermal expansion issues. Lubricate every 500,000 cycles
using ISO VG32 hydraulic oil.
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Free Mount Cylinder MUR12X15 Specifications
- Model: MUR12X15
- Type: Single-acting spring return cylinder (Free mount design)
- Bore size: 12mm (0.47")
- Stroke: 15mm (0.59")
- Operating pressure: 0.05–0.9 MPa (7–130 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5x0.8 (Standard) / Optional NPT1/8 adapter
- Cushioning: Rubber buffer + adjustable cushion screw
- Material: Aluminum alloy barrel, Stainless steel piston rod (SUS304)
- Seal material: NBR (Nitrile) with grease retention structure
- Weight: 0.23 kg (0.51 lbs)
- Dimensions:
- Length (retracted): 74mm (2.91")
- Width (body): 24mm (0.94")
- Height (mounting base): 34mm (1.34")
- Rod end thread: M4x0.7 internal thread
- Protection rating: IP67 (Dust tight & protected against immersion)
- Lubrication: Pre-lubricated (Oil-free operation possible)
Ultra-compact pneumatic cylinder featuring 360° free mounting capability through integrated T-slot design. Precision-engineered with dual anti-rotation guides for stable linear motion, ideal for space-constrained automation systems. Anodized surface treatment enhances corrosion resistance in humid environments.
Typical Applications:
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical packaging
- Precision lens positioning in optical equipment
- Miniature clamping devices for watchmaking
- Automated lab sample tray indexers
Installation note:
For vertical mounting, use locknuts on both sides of mounting slot.
Maintain 0.5-1mm clearance between cylinder base and mounting surface
to prevent thermal expansion issues. Lubricate every 500,000 cycles
using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | MUR12X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
