Airtac MUR Compact Free Mount Cylinder MUR12X35B
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR12X35B Compact Free Mount Cylinder Specifications
- Model Series: MUR (Compact Free Mount Series)
- Bore Size: 12mm
- Stroke: 35mm
- Action Type: Double-acting
- Mounting Style: Free mount (no fixed bracket)
- Material: Aluminum alloy cylinder tube, stainless steel piston rod
- Seal Material: NBR (Nitrile Rubber)
- Operating Pressure: 0.15-0.8 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable buffer (both ends)
- Port Size: M5x0.8
- Weight: 0.28kg (excluding accessories)
- Dimensions: 105mm(L) x 30mm(W) x 30mm(H) (at mid-stroke position)
- Rod Thread: M6x1.0
- Protection Rating: IP65
- Mounting Hole Spacing: 16mm (vertical) x 25mm (horizontal)
- Max Theoretical Thrust: 67.8N @0.5MPa
Ultra-compact cylinder featuring space-saving design with 20% reduced footprint compared to standard models. Precision-machined guide grooves enable direct mounting without brackets, ideal for modular automation systems. Anodized surface treatment enhances corrosion resistance in humid environments. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- PCB handling robots in electronics assembly
- Micro-dosing valves in medical analyzers
- Clamping mechanisms in SMT equipment
- Actuation of small grippers in pick-and-place systems
- Valve switching in compact pneumatic circuits
Installation guidance:
Ensure proper alignment using the built-in mounting grooves (tolerance ±0.2mm).
Apply thread locker on mounting screws when used in high-vibration environments.
Allow 5mm clearance around cylinder body for heat dissipation during continuous operation.
| Property | Property Value |
|---|---|
| sku | MUR12X35B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 35mm |
