Airtac MUR Compact Free Mount Cylinder MUR20X50
$28.81
Regular price
$36.31
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MUR20X50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
Operation guidance:
Achieve peak performance by maintaining 0.1-1.0μm filtered air supply with ISO VG32 lubricant.
For vertical installations, add 15% extra thrust margin. Replace rod wiper seals every 500,000 cycles.
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Cylinder MUR20X50 Technical Details
- Model: MUR20X50
- Type: Double-acting, compact free mount cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 50mm (customizable 25-300mm)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Rubber buffer (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston rod thread: M6x1.0 external thread
- Temperature range: -20℃ to 80℃
- Cylinder tube material: Anodized aluminum alloy
- Piston rod material: Chrome-plated steel
- Seal material: NBR/PU compound seals
- Weight: 280g ±5% (excluding accessories)
- Dimensions:
- Body diameter: 20mm
- Extended length: 148mm (stroke 50mm)
- Retracted length: 98mm (stroke 50mm)
- Mounting base: 32mm x 32mm square profile
- ISO standard: 6432/DIN ISO 15552 compliant
The MUR20X50 features a space-saving mono-block design with 360° adjustable mounting points. Its dual piston seals and chromed rod ensure 2,000km+ service life under standard conditions. The cylinder operates at ≤1.5dB(A) noise level with optimized air consumption of 2.1L/min at 0.5MPa.
Implementation Scenarios:
- PCB handling robots requiring precise linear motion
- Pharmaceutical blister packaging machines
- Semiconductor wafer clamping mechanisms
- Automated coffee machine brew group actuators
- 3D printer filament feed control systems
Operation guidance:
Achieve peak performance by maintaining 0.1-1.0μm filtered air supply with ISO VG32 lubricant.
For vertical installations, add 15% extra thrust margin. Replace rod wiper seals every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | MUR20X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
