Airtac NPM Clamp Cylinder NPM35T63X13AI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13AI T-Slot Type Knife Edge Cylinder Specifications
- Model: NPM35T63X13AI
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: T-slot base with precision alignment grooves
- Port size: M5x0.8 (standard), G1/8 optional
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: NBR wear-resistant seals
- Repeat accuracy: ±0.2mm
- Weight: 1.65kg (without accessories)
- Dimensions: 150mm(L) × 52mm(W) × 51mm(H)
- Protection class: IP54 (standard), IP67 optional
High-precision knife edge cylinder optimized for vertical tool changing systems, featuring ultra-flat T-slot design for direct machine mounting. The special tungsten-coated blade edge ensures 500,000+ cycle durability under heavy side loads. Integrated shock absorption system reduces vibration during high-speed (≤1.5m/s) operation.
- CNC machining center tool changers
- PCB drilling machine Z-axis actuators
- Laser cutting head positioning systems
- Automated robotic gripper mechanisms
- Precision die-casting mold clamping
Installation note:
Ensure blade edge alignment within 0.1mm tolerance during assembly.
Use 32# hydraulic oil for lubrication. Requires weekly inspection of
scraper seals in high particulate environments.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13AI |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
