Airtac NPM Clamp Cylinder NPM35T63X13AIL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM Series Punching Cylinder NPM35T63X13AIL Specifications
- Model: NPM35T63X13AIL
- Type: Compact punch-type cylinder (Double-acting)
- Bore size: 35mm
- Stroke: 13mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber bumper + air cushion
- Temperature range: -10℃ to 80℃
- Seal material: Polyurethane (PU) with wear-resistant ring
- Mounting: Standard ISO/VDMA flange mounting
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Sensor option: Built-in magnet for magnetic switch (M9/M12)
- Weight: 0.9kg (typical)
- Dimensions: 152mm(L) × 54mm(W) × 54mm(H)
High-precision punching cylinder designed for rapid tool clamping in machining centers. Features dual cushioning system for shock absorption and anti-rotation guide rod structure for precise linear motion. The hardened stainless steel piston rod (HRC 45-50) ensures durability in high-cycle applications.
- CNC tool changers in vertical/horizontal machining centers
- Precision drilling & tapping machine tool holders
- Automated fixture clamping systems
- High-speed punching mechanisms in PCB manufacturing
- Multi-axis robotic arm end effectors
Operation notes:
Requires ISO VG32 hydraulic oil mist lubrication (1 drop/m³).
Use 5μm filtered dry air. Avoid side load exceeding 15N.
Alignment tolerance: ±0.2mm perpendicular to mounting surface.
- Relubrication: Every 500,000 cycles
- Seal replacement: 3,000km cumulative travel distance
- Bumper inspection: Monthly in continuous operation
| Property | Property Value |
|---|---|
| sku | NPM35T63X13AIL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
