Airtac NPM Clamp Cylinder NPM35T63X13AL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13AL Striker Cylinder Specifications
- Model: NPM35T63X13AL
- Type: Double-acting striker cylinder (compact series)
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable rubber buffer
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Mounting type: Front flange with tapped holes
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, CR seals
- Weight: 1.25kg ±3%
- Dimensions: 208mm(L) × 50mm(W) × 50mm(H)
- Rod thread: M13x1.5 striker interface
- Repetition accuracy: ±0.2mm
- ISO standard: 6432 compliant
Precision striker cylinder designed for high-speed tool changing in CNC machinery, featuring enhanced lateral load capacity through integrated guide grooves. The hardened piston rod (HRC 45-50) and double lip seals ensure durability in high-cycle applications. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Automatic tool changers in machining centers
- Indexing mechanism drives
- Press-fit assembly systems
- Laser cutting machine positioning
- High-speed sorting equipment
Installation note:
Maintain 0.05-0.2mm clearance between striker rod and tool holder.
Use anti-vibration washers when mounting on dynamic platforms.
Lubricate every 500,000 cycles under normal operation.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13AL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
