Airtac NPM Clamp Cylinder NPM35T63X13CIL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13CIL Rodless Striker Cylinder Specifications
- Model: NPM35T63X13CIL
- Type: Compact rodless cylinder with magnetic piston
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.05–1.0 MPa
- Piston material: Aluminum alloy (hard anodized)
- Seal material: NBR/PU hybrid seals
- Mounting type: C-shaped (standard) with multiple accessory holes
- Cushioning: Adjustable hydraulic buffer (dual-end)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (DOP mist compatible)
- Weight: 1.45kg ±2%
- Dimensions: 221mm(L) × 50mm(W) × 35mm(H)
- Repeat accuracy: ±0.1mm
- Max speed: 700mm/s
- Port size: M5x0.8 (standard), optional Rc1/8
- Protection rating: IP54 (standard), IP67 optional
High-precision linear actuator with integrated T-slot striker mechanism, designed for vertical tool changing and high-speed positioning. Features anti-rotation guidance system and wear-resistant chromium-plated shaft. The X13CIL variant includes enhanced dust wipers and inertial dampening for impact reduction.
- CNC machine tool changers
- PCB drilling equipment positioning
- Automated robotic pick-and-place systems
- Laser cutting machine Z-axis control
- High-cycle injection molding ejectors
Installation note:
Requires periodic lubrication (every 500km travel). Avoid side-load forces exceeding 15N.
For vertical mounting, use auxiliary guide rails when payload exceeds 2.5kg.
Minimum 0.3MPa pressure recommended for stable magnetic coupling.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13CIL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC 110V |
| Hydraulic Cylinder Bore | 63mm |
