Airtac NPM Clamp Cylinder NPM35T63X13CL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13CL Guillotine Cylinder Specifications
- Model: NPM35T63X13CL
- Type: Compact double-acting guillotine cylinder
- Bore size: 35mm
- Stroke: 63mm
- Rod diameter: 13mm (precision ground chrome-plated)
- Operating pressure: 0.15–0.8 MPa
- Mounting style: CL series front flange (ISO 15552 compatible)
- Cushioning: Adjustable air cushion at both ends
- Temperature range: -20℃ to 80℃
- Seal material: NBR (nitrile) with wear-resistant ring
- Body material: Aluminum alloy (anodized finish)
- Weight: 2.4kg ±5% (without accessories)
- Dimensions: 200mm(L) × 58mm(W) × 58mm(H) (at full extension)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston speed: 50–800 mm/s (lubricated operation)
- Protection rating: IP54 (standard sealing)
A high-precision guillotine-style cylinder engineered for vertical cutting/pressing applications. Features dual anti-rotation guide rods (13mm) for exceptional lateral stability during shearing operations. The T-slot mounting design enables quick blade replacement and force adjustment through counterbalance weights.
- CNC material cutting systems
- PCB depaneling machines
- Rubber/silicone sheet punching
- Automated paper/cardboard guillotines
- Textile sample cutting devices
Installation note:
Maintain 0.02-0.05mm clearance between blade and guide blocks during assembly.
Use locking adhesive on mounting bolts (recommended torque: 5.8N·m).
Pre-lubricate with ISO VG32 hydraulic oil for initial operation.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13CL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC 110V |
| Hydraulic Cylinder Bore | 63mm |
