Airtac NPM Clamp Cylinder NPM35T63X13EI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13EI Knife Edge Cylinder Specifications
- Model: NPM35T63X13EI
- Type: Double-acting knife edge cylinder
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.15–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Rectangular flange (ISO 15552 standard)
- Port size: 1/4" NPT (M5 optional)
- Piston rod thread: M12×1.25
- Material: Aluminum alloy body, hard chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 1.65kg ±2%
- Dimensions: 224mm(L) × 76mm(W) × 76mm(H)
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (relubrication interval: 3,000km)
High-precision cylinder with integrated knife-edge groove (13mm width) for tooling plate mounting, featuring enhanced lateral load capacity through optimized guide design. The EI suffix indicates extended impact resistance for high-cycle applications. Requires 5μm filtered air with ISO 8573-1:2010 class 3 air quality.
- CNC machine tool changers
- Automated fixture clamping systems
- Robotic welding positioners
- Semiconductor wafer handling equipment
- High-speed sorting mechanisms
Installation note:
Align knife-edge groove with mating surface within 0.1mm tolerance.
Use anti-vibration washers in high-frequency applications.
Maximum side load: 35N at mid-stroke. Lubricate rod weekly in continuous operation.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13EI |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC24V |
| Hydraulic Cylinder Bore | 63mm |
