Airtac NPM Clamp Cylinder NPM35T63X13F
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM Series Punching Cylinder NPM35T63X13F Specifications
- Model: NPM35T63X13F
- Type: Double-acting punching cylinder (with integrated guide)
- Bore size: Ø35mm
- Stroke: 63mm
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 80℃
- Cushioning type: Adjustable rubber bumper
- Mounting style: Horizontal flange mounting (MF1 type)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston rod thread: M12x1.25
- Seal material: Polyurethane (PU) with wear-resistant ring
- Repeat positioning accuracy: ±0.05mm
- Max. speed: 500mm/s
- Protection rating: IP54
- Weight: 1.85kg ±2%
- Dimensions: 213mm(L) × 70mm(W) × 70mm(H)
High-precision punching cylinder with integrated guide mechanism, designed for vertical punching/stamping operations requiring extreme positional accuracy. Features hardened chromium-plated rod and dual anti-rotation guides (X-axis & Y-axis) for enhanced stability. Requires 25μm filtered dry air with ISO VG32 lubrication.
- CNC turret punch press tool changers
- Automated circuit board stamping systems
- Precision metal marking machines
- High-speed packaging line punch mechanisms
- Semiconductor wafer processing equipment
Installation note:
Ensure perpendicular alignment within 0.02mm/m tolerance. Use lock nuts (not included)
with 18-22N·m torque. Lubricate rod weekly with ISO VG32 equivalent grease.
Maximum side load: 150N (axial direction only).
| Property | Property Value |
|---|---|
| sku | NPM35T63X13F |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC12V |
| Hydraulic Cylinder Bore | 63mm |
