Airtac NPM Clamp Cylinder NPM45T63X13A
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM Series Punching Cylinder NPM45T63X13A Technical Details
- Model Code: NPM45T63X13A
- Type: Compact punch-type double-acting cylinder
- Bore size: 45mm (ISO 6432 standard)
- Stroke: 63mm (adjustable cushioning ±3mm)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (lubricated)
- Ambient temperature: -10℃ to 70℃
- Port size: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable elastic buffer + air cushion
- Piston material: High-grade aluminum alloy (hard anodized)
- Rod coating: Hard chromium-plated (25μm thickness)
- Seal type: NBR + special wear-resistant ring
- Weight: 1.68 kg (without accessories)
- Dimensions: 156mm(L) × 45mm(Bore) × 57mm(Mounting height)
- Stroke tolerance: +1.5mm/-0mm
- Mounting: Basic type (MF1) with front flange
- Accessory ready: Built-in magnet for magnetic sensor (SM series compatible)
High-precision punching cylinder with integrated impact absorption system, featuring dual anti-rotation guide rods for enhanced stability during high-speed punching operations. The T-slot mounting surface (ISO 15552 compliant) enables secure fixture alignment. Optional auto-lubrication unit available for maintenance-free cycles.
- CNC tool changers in machining centers
- Stamping press ejection mechanisms
- PCB depaneling equipment
- Automated riveting systems
- Sheet metal punching stations
- Precision gear assembly presses
Operational note:
Maintain 0.3–0.5 MPa air pressure for initial 50 cycles to seat seals properly.
Use ARD-02 lubricator when operating below -5℃. Replace cushion seals every
500,000 cycles in high-impact applications.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13A |
| Output Force | Output Force 4500kg |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
