Airtac NPM Clamp Cylinder NPM45T63X13AI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM45T63X13AI Knife Edge Cylinder Specifications
- Model: NPM45T63X13AI
- Type: Double-acting knife edge cylinder
- Bore size: 45mm
- Stroke: 13mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–700 mm/s
- Ambient temperature: -10℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Port size: M5x0.8 (standard), G1/8 optional
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR + PU combination
- Weight: 0.68 kg (bare cylinder)
- Dimensions: 112mm(L) × 45mm(Bore) × 63mm(Height)
- Mounting type: AI series (front flange with tapped holes)
- Position detection: Built-in magnet (SMCR8-15 compatible)
- Protection rating: IP54 (standard), IP67 optional
Precision-engineered knife edge cylinder optimized for high-speed positioning in confined spaces. Features reinforced edge geometry for chip resistance and wear compensation mechanism. The anti-rotation design maintains tool orientation during rapid cycling (up to 5Hz). Requires ISO 8573-1:2010 class 3 compressed air.
- CNC tool changer mechanisms
- PCB drilling machine Z-axis actuators
- Laser cutting head positioning
- High-speed sorting gate actuators
- Semiconductor wafer handling robots
Installation note:
Requires periodic lubrication (every 500km stroke) with ISO VG32 turbine oil.
Avoid side loads exceeding 15N. For vertical mounting, use counterbalance valves.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13AI |
| Output Force | Output Force 4500kg |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
