Airtac NPM Clamp Cylinder NPM45T63X13AL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM45T63X13AL Striker Cylinder Specifications
- Model: NPM45T63X13AL
- Type: Compact ISO 6432 striker cylinder (double-acting)
- Bore size: 45 mm
- Stroke: 63 mm
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting: Front/rear flange (ISO 15552 standard)
- Port size: 1/4" NPT (G1/8 optional)
- Piston rod thread: M12×1.5
- Weight: 2.1 kg (with standard accessories)
- Dimensions: 183mm(L) × 45mm(W) × 45mm(H)
- Rod end type: Male thread + through-hole
- Seal material: Polyurethane (NBR optional)
- Repetition accuracy: ±0.2 mm
Ultra-compact striker cylinder designed for high-speed tool changing in CNC machining centers. Features anodized aluminum construction with hardened chromium piston rod (HRC 45-50). The X13AL variant includes enhanced guide bushings for lateral load resistance, making it ideal for precision positioning tasks. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Automatic tool changers in vertical/horizontal machining centers
- Precision clamping systems for CNC fixtures
- High-speed sorting mechanisms in packaging lines
- Position locking in robotic welding arms
- Material handling in semiconductor manufacturing
Installation note:
Ensure coaxial alignment within 0.2mm tolerance during mounting. For vertical installations,
use counterbalance valves when stroke speed exceeds 500 mm/s. Lubricate through air line
(0.3-1.0 cm³/min oil mist recommended).
| Property | Property Value |
|---|---|
| sku | NPM45T63X13AL |
| Output Force | Output Force 4500kg |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
