Airtac NPM Clamp Cylinder NPM45T63X13BI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM Series NPM45T63X13BI Knife Edge Cylinder Specifications
- Model: NPM45T63X13BI
- Type: Double-acting compact cylinder with knife-edge design
- Bore size: 45mm
- Stroke: 63mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Magnet: Built-in magnetic sensor (BI suffix)
- Piston rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Ambient temperature: -20℃ to 80℃
- Weight: 1.65kg ±3%
- Dimensions (L×W×H):
- Extended length: 204mm
- Retracted length: 141mm
- Body width: 45mm
- Mounting height: 63mm
Ultra-slim profile cylinder (13mm thickness) with precision-ground knife-edge surfaces for space-constrained installations. Features triple sealing system for leak prevention and dual guide rods for enhanced lateral load capacity. Integrated sensor groove accommodates multiple proximity switch types.
- CNC machine tool clamping mechanisms
- Robotic end-effector positioning
- Semiconductor wafer handling systems
- High-speed sorting equipment
- Plastic injection molding ejectors
Installation guidelines:
Use ISO 6432 mounting accessories (specify MBTxx series brackets).
Maintain 0.5mm minimum clearance between knife edges and mating surfaces.
Lubricate with ISO VG32 hydraulic oil during initial installation.
For vertical mounting, install air exhaust downward.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13BI |
| Output Force | Output Force 4500kg |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
