Airtac NPM Clamp Cylinder NPM45T63X13BL
$355.90
Regular price
$363.40
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
NPM45T63X13BL
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Specialized sealing materials ensure exceptional leak-tight performance in hydraulic cylinder operation;
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
Installation note:
Apply 0.3mm preload on mounting bolts using cross-tightening pattern.
Maintain 0.5-1mm clearance between striker head and target surface
during initial alignment. Lubricate every 50km of cumulative stroke.
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM45T63X13BL Striker Cylinder Technical Details
- Model: NPM45T63X13BL
- Type: Compact striker cylinder (double-acting)
- Bore size: 45mm
- Stroke: 63mm
- Rod diameter: 13mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (standard), G1/8 optional
- Cushion type: Adjustable rubber bumper (both ends)
- Body material: Aluminum alloy (anodized)
- Rod material: Stainless steel (SUS304)
- Seal type: NBR + PU combination
- Weight: 1.65kg ±2%
- Dimensions: 156mm(L) × 60mm(W) × 60mm(H)
- ISO standard: 6432 (mounting dimensions)
- Protection class: IP54 (standard), IP67 optional
Precision-engineered striker cylinder with integrated impact absorption, featuring wear-resistant chromium-plated guide bushings and anti-rotation mechanism. The T-slot mounting design enables 360° adjustable positioning. Requires ISO VG32 hydraulic oil or equivalent lubrication.
Typical Applications:
- CNC machine tool automatic tool changers
- Stamping press ejection systems
- Robotic welding positioners
- High-speed sorting mechanisms
- Glass processing equipment
Installation note:
Apply 0.3mm preload on mounting bolts using cross-tightening pattern.
Maintain 0.5-1mm clearance between striker head and target surface
during initial alignment. Lubricate every 50km of cumulative stroke.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13BL |
| Output Force | Output Force 4500kg |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
