Airtac NPM Clamp Cylinder NPM45T63X13C
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM45T63X13C Blade Cylinder Specifications
- Model: NPM45T63X13C
- Type: Double-acting linear guide cylinder (Punching type)
- Bore size: 45mm
- Stroke: 63mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–700 mm/s
- Mounting type: C-type (Front flange with tapped holes)
- Cushioning: Adjustable pneumatic cushion
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Material: Aluminum alloy body, hardened steel piston rod
- Seal material: NBR + Polyurethane
- Temperature range: -10℃ to 80℃
- Weight: 2.8 kg (with standard accessories)
- Dimensions: 180mm(L) × 67mm(W) × 63mm(H)
- Rod end type: External thread M12x1.25
- Protection rating: IP54 (Standard) / IP67 (Optional)
High-precision linear guide cylinder with integrated blade mechanism, designed for punching/marking applications requiring micron-level repeatability. Features dual piston seals and chrome-plated guide shafts for contamination resistance. Requires 5μm filtered dry air (ISO 8573-1:2010 Class 3.4.2).
- CNC machine tool automatic tool changers
- PCB depaneling equipment
- Precision stamping systems
- Automated laser marking stations
- Semiconductor wafer handling robots
Operation note:
Maintain 0.3-0.5 MPa lubrication pressure for blade mechanism.
For vertical mounting, use supplemental support brackets when vibration >0.5G.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13C |
| Output Force | Output Force 4500kg |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC 110V |
| Hydraulic Cylinder Bore | 63mm |
