Airtac NPM Clamp Cylinder NPM45T63X13CI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM45T63X13CI Punching Cylinder Specifications
- Model: NPM45T63X13CI
- Type: Compact punch-type double-acting cylinder
- Bore size: 45mm
- Stroke: 63mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard), G1/8 optional
- Mounting style: Foot-mounted (MF1) with accessory options
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + Polyurethane hybrid
- Weight: 1.25kg ±3% (excluding accessories)
- Dimensions:
- Length: 191mm (full retracted)
- Width: 55mm (mounting foot span)
- Height: 45mm (body diameter)
- IP rating: IP54 (standard), IP67 with optional wipers
- Max speed: 500mm/s (with cushion)
High-speed precision cylinder with integrated punch mechanism, featuring enhanced lateral load capacity through dual guide rod design. The T-slot mounting surface allows direct tooling attachment, while the chrome-plated piston rod resists abrasive wear in high-cycle applications. Requires 5μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- PCB depaneling machines (V-cut separation)
- Automated stamping/punching systems
- Sheet metal embossing equipment
- High-speed sorting mechanisms
- Robotic deburring end-effectors
Installation note:
Maintain parallel alignment within 0.2mm/m during mounting. For vertical installations,
use locknut (ASNU05) to prevent stroke deviation. Lubricate guide shafts weekly
in dusty environments.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13CI |
| Output Force | Output Force 4500kg |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC 110V |
| Hydraulic Cylinder Bore | 63mm |
