Airtac PA Nylon Tube PA12040025200MGE
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tubing PA12040025200MGE Technical Details
- Full Model Code: PA12040025200MGE
- Material: Polyamide 12 (PA12) reinforced nylon
- Inner Diameter: 12.0 mm ±0.2mm
- Outer Diameter: 14.0 mm ±0.3mm
- Standard Length: 200 meters/roll
- Wall Thickness: 1.0 mm ±0.1mm
- Burst Pressure: ≥12 MPa (at 23℃)
- Working Pressure: 0.3-1.0 MPa
- Temperature Range: -40℃ to +80℃ (short-term 120℃)
- Bending Radius: ≥5×OD (70mm minimum)
- Color: Standard blue with white tracer line
- Certification: RoHS compliant, ISO 11439 tested
- Weight: 0.285 kg/m → 57kg/roll (200m)
- Coil Dimensions: 400mm(W) × 400mm(H) × 250mm(D)
- End Fitting Compatibility: 1/2" BSPP, 3/8" JIC, or custom crimp fittings
Multi-layer extruded nylon tubing with exceptional kink resistance and memory retention. Features UV-stabilized construction with embedded anti-static wire (surface resistance ≤10⁶Ω). The internal smooth bore minimizes pressure drop, while the abrasion-resistant outer layer withstands 50,000+ flex cycles. Compatible with compressed air, vacuum systems, and inert gases.
- CNC machine tool pneumatic tool changers
- Automated packaging line actuator systems
- Lithium battery production dry room environments
- Food-grade air supply (FDA-compliant version available)
- Robotic welding cell air blast systems
Installation protocol:
Use rotary tube cutter for clean ends. Allow 24hrs acclimation at >20℃ before pressurization.
Maximum continuous vibration: 25g @ 200Hz. Replace every 5 years or 15,000 operating hours.
| Property | Property Value |
|---|---|
| sku | PA12040025200MGE |
| Inner Diameter | <2.5 mm> |
| Wall Thickness | <0.75 mm> |
| Outer Diameter | 4.0mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -40 to 70 |
| Bend Radius | <25 mm> |
| Length per Roll | 200mm |
| Color Code | Orange |
