Description
1. PA12 and PA6 nylon tubing excel in high-pressure environments with superior mechanical properties.
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
Installation guidelines:
Maintain minimum bend radius of 80mm during routing. For pressurized applications above 0.6MPa,
use tube supports every 1.5m. Perform air purge (0.3MPa × 30s) before initial use to remove manufacturing residues.
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tube PA12040025200MY Technical Specifications
- Full Model Code: PA12040025200MY
- Material: Polyamide 12 (PA12) reinforced nylon
- Inner Diameter: 12.0mm ±0.2mm
- Outer Diameter: 14.0mm ±0.3mm
- Standard Length: 25,200mm (25.2 meters/82.68 ft per coil)
- Burst Pressure: ≥12.0MPa @23℃
- Working Pressure: 0.3-1.0MPa (3-10 bar)
- Temperature Range: -40℃ to +80℃ (short-term +120℃ for ≤1hr)
- Weight: 1.82kg/m ±5% (Total coil weight: ~45.9kg)
- Coil Dimensions: 600mm(W) × 600mm(D) × 400mm(H)
- Color Code: Blue spiral stripe on natural nylon base
- Certifications: RoHS compliant, REACH SVHC-free
- Surface Roughness: Ra ≤3.2μm (internal bore)
Multi-layer extruded nylon tubing with embedded anti-static wire (MY suffix), featuring exceptional kink resistance and 360° bend capability. The helical blue stripe enables visual wear inspection. Compatible with ISO 14743 pneumatic quick connectors.
Industrial Applications:
- CNC machine tool coolant delivery systems
- Robotic arm pneumatic gripper installations
- Electroplating equipment chemical transfer lines
- Semiconductor cleanroom vacuum circuits
- High-cycle packaging machine air networks
Installation guidelines:
Maintain minimum bend radius of 80mm during routing. For pressurized applications above 0.6MPa,
use tube supports every 1.5m. Perform air purge (0.3MPa × 30s) before initial use to remove manufacturing residues.
Fluid Compatibility:
- Excellent: Compressed air, hydraulic oils (ISO VG32-68)
- Good: Water-glycol mixtures, mild alkalis (pH <10)
- Avoid: Strong acids, halogenated hydrocarbons, concentrated oxidizers
| Property | Property Value |
|---|---|
| sku | PA12040025200MY |
| Inner Diameter | <2.5 mm> |
| Wall Thickness | <0.75 mm> |
| Outer Diameter | 4.0mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -40 to 70 |
| Bend Radius | <25 mm> |
| Length per Roll | 200mm |
| Color Code | Yellow |
