Airtac PA Nylon Tube PA12060040100MBU
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tubing PA12060040100MBU Technical Specifications
- Full Model Code: PA12060040100MBU
- Material: Polyamide 12 (PA12) reinforced nylon
- Outer Diameter (OD): 12.0 mm ±0.2mm
- Inner Diameter (ID): 6.0 mm ±0.15mm
- Wall Thickness: 3.0 mm ±0.1mm
- Burst Pressure: ≥8.0 MPa at 23℃
- Operating Pressure Range: -0.1 to 1.6 MPa
- Temperature Range: -40℃ to +80℃ (instantaneous +120℃)
- Bending Radius: ≥4×OD (48mm minimum)
- Color Code: MBU (Medium Blue with UV-resistant additive)
- Surface Finish: Smooth bore (Ra ≤0.8μm)
- Permeability: ≤15 mg/(m²·24h) @40℃, 95%RH
- Certifications: RoHS 3, REACH, FDA 21 CFR 177.1500 compliant
- Weight: 0.98 kg/m ±3%
- Standard Coil Dimensions: 30cm (H) × 40cm (W) × 25cm (D) per 100m coil
High-flex PA12 tubing with enhanced kink resistance and permanent anti-static properties (surface resistance 10⁶-10⁹Ω). Features triple-layer construction with embedded fiber reinforcement for improved pressure retention. The UV-stabilized formulation prevents degradation in outdoor applications.
- Robotic end-effector pneumatic circuits
- CNC machine tool coolant line protection sleeves
- Pharmaceutical cleanroom compressed air distribution
- Food processing equipment steam line insulation jackets
- Electric vehicle battery cooling system conduits
Installation Guidelines:Use brass or POM compression fittings with 60-65 Shore A hardness seals. For pressurized connections, maintain 1.5×OD straight lead-in before bends. When cutting, deburr inner edges with RG-6 reamer tool to prevent flow turbulence. Annual inspection recommended for high-cycle applications (>500,000 flex cycles).
Avoid:Continuous exposure to ester-based lubricants or chlorinated solvents. Not suitable for acetylene or ozone-rich environments. Maximum angular misalignment during installation: ±2° from fitting axis.
| Property | Property Value |
|---|---|
| sku | PA12060040100MBU |
| Inner Diameter | 4.00 mm |
| Wall Thickness | 1.00mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -40 to 70 |
| Bend Radius | 35mm |
| Length per Roll | Stroke 100mm |
| Color Code | Blue |
