Airtac PA Nylon Tube PA6040025200MBK
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tubing PA6040025200MBK Technical Details
- Full model: PA6040025200MBK
- Material: PA12 (Polyamide 12) with UV stabilizers
- Color code: MBK (Matte Black)
- Outer diameter: 6.0mm ±0.1mm
- Inner diameter: 4.0mm ±0.05mm
- Standard length per coil: 25 meters
- Weight per meter: 0.048kg/m ±5%
- Total coil weight: 1.2kg (including packaging)
- Burst pressure: ≥20 bar at 23℃
- Working pressure: 0-12 bar (recommended 8 bar for extended service life)
- Temperature range: -40℃ to +80℃ (short-term peak 100℃ for ≤1hr)
- Minimum bending radius: 25mm (ambient temp)/40mm (below -10℃)
- Certification: RoHS compliant, REACH SVHC-free
- Oil resistance: Compatible with ISO VG32 hydraulic oils
- Gas permeability: ≤15ml/m²·24hr·bar (N₂ @ 23℃)
- Coil dimensions: 320mm(W) × 320mm(D) × 120mm(H)
High-flex PA12 tubing with enhanced kink resistance and memory retention. Features a smooth inner bore for optimized airflow (≤2% pressure drop @ 6m/s). Anti-static formulation (surface resistance 10^9-10^11Ω) prevents dust adhesion. Includes UV protection for outdoor applications up to 2000hrs @ 0.76W/m² UV-B exposure.
- Robotic end-effector pneumatic lines (ISO 9409-1 compatible)
- CNC machine tool coolant delivery systems
- Food processing equipment (FDA-compliant version available as PA6040025200MWT)
- EV battery cooling system prototyping
- Laboratory vacuum line connections
Installation guidelines:
Use tube cutters for clean perpendicular cuts. For push-to-connect fittings,
insert until 1mm protrusion remains. Avoid exposure to halogenated hydrocarbons.
Pre-stretch by 2-3% when routing through cable carriers.
| Property | Property Value |
|---|---|
| sku | PA6040025200MBK |
| Inner Diameter | <2.5 mm> |
| Wall Thickness | <0.75 mm> |
| Outer Diameter | 4.0mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | 30mm |
| Length per Roll | 200mm |
| Color Code | Black |
