Airtac PA Nylon Tube PA6040025200MBU
$76.73
Regular price
$84.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PA6040025200MBU
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. PA12 and PA6 nylon tubing excel in high-pressure environments with superior mechanical properties.
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
Installation protocol:
Use tube cutters for clean perpendicular cuts. Minimum bend radius = 4×OD (24mm).
For pressurized applications above 0.6MPa, install support sleeves at connection points.
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tubing PA6040025200MBU Technical Specifications
- Full Model Code: PA6040025200MBU
- Material: Polyamide 12 (PA12) reinforced nylon
- Inner Diameter: 4.0 mm ±0.1mm
- Outer Diameter: 6.0 mm ±0.15mm
- Wall Thickness: 1.0 mm nominal
- Length per Coil: 25 meters (standard package)
- Burst Pressure: ≥12 MPa at 23℃
- Working Pressure: 0.3-1.0 MPa (recommended operating range)
- Temperature Range: -40℃ to +80℃ (short-term +120℃ for <1hr)
- Weight per Meter: 0.021 kg/m ±5%
- Total Coil Weight: 5.25 kg (including protective packaging)
- Coil Dimensions: 320mm(W) × 320mm(D) × 180mm(H)
- Color Code: MBU = Medium Blue with white tracer line
- Certification: ROHS compliant, REACH SVHC-free
- Surface Finish: Smooth bore (Ra ≤0.8μm internal)
High-flex PA tubing engineered for precision pneumatic systems requiring chemical resistance and memory retention. Features anti-kink helical reinforcement and UV-stabilized formulation. The white tracer line enables quick visual circuit identification in multi-line installations.
Industrial Applications:
- Robotic end-effector tooling air supply
- CNC machine coolant mist extraction lines
- Pharmaceutical blister packaging air knives
- EV battery assembly vacuum gripper systems
- Food processing pneumatic actuator networks
Installation protocol:
Use tube cutters for clean perpendicular cuts. Minimum bend radius = 4×OD (24mm).
For pressurized applications above 0.6MPa, install support sleeves at connection points.
Resistance Profile:
- Excellent: Hydraulic oils, aliphatic hydrocarbons
- Good: 20% sulfuric acid, mild alkalis
- Poor: Phenols, concentrated oxidizing acids
| Property | Property Value |
|---|---|
| sku | PA6040025200MBU |
| Inner Diameter | <2.5 mm> |
| Wall Thickness | <0.75 mm> |
| Outer Diameter | 4.0mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | 30mm |
| Length per Roll | 200mm |
| Color Code | Blue |
