Airtac PA Nylon Tube PA6040025200MN
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tubing PA6040025200MN Technical Specifications
- Model: PA6040025200MN
- Material: Polyamide 12 (PA12) reinforced nylon
- Inner Diameter: 4.0 mm ±0.1mm
- Outer Diameter: 6.0 mm ±0.2mm
- Wall Thickness: 1.0 mm nominal
- Working Pressure: 0.8 MPa (8 bar) at 23℃
- Burst Pressure: ≥2.4 MPa (24 bar)
- Temperature Range: -40℃ to +80℃ (short-term 100℃ for 1hr)
- Bend Radius: Minimum 20mm (4x OD)
- Color: Natural translucent (UV-resistant additive)
- Weight: 0.052 kg/m ±5% → ~10.4 kg/200m coil
- Coil Dimensions: 300mm (W) × 300mm (D) × 180mm (H)
- Certifications: RoHS compliant, REACH SVHC-free
- Permeability: ≤15 mg/(m²·24h) for air at 23℃
High-flex PA tubing with spiral reinforcement, engineered for precision pneumatic systems requiring kink resistance and dimensional stability. Features low particulate emission and smooth inner surface (Ra ≤0.8μm) for optimized airflow. Compatible with ISO 14743 push-to-connect fittings.
- CNC machine tool pneumatic circuits
- Food-grade compressed air systems (FDA-compliant version available)
- Laboratory analytical instrument gas supply
- Automated packaging line actuator controls
- Semiconductor manufacturing equipment
Installation guidelines:
Allow 10% extra length for thermal expansion (0.15mm/m/℃).
Use tube cutters (not knives) for clean square ends.
Maximum continuous vibration: 25g @ 50Hz.
| Property | Property Value |
|---|---|
| sku | PA6040025200MN |
| Inner Diameter | <2.5 mm> |
| Wall Thickness | <0.75 mm> |
| Outer Diameter | 4.0mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | 30mm |
| Length per Roll | 200mm |
| Color Code | Natural |
