Airtac PA Nylon Tube PA6040025200MR
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tubing PA6040025200MR Technical Specifications
- Material: PA12 (Polyamide 12) reinforced nylon
- Inner diameter: 4.0 mm ±0.1 mm
- Outer diameter: 6.0 mm ±0.15 mm
- Standard length: 25 meters/roll (custom lengths available)
- Operating temperature: -40℃ to +80℃ (short-term +120℃)
- Max working pressure: 12 bar (1.2 MPa) at 23℃
- Burst pressure: ≥36 bar
- Bending radius: ≥20 mm (non-kinking design)
- Color: Standard blue with white tracer line (customizable)
- Weight: 0.035 kg/m ±5% (0.875 kg/25m roll)
- Coil dimensions: 320mm(W) × 320mm(D) × 240mm(H)
- Certification: FDA compliant (food contact), RoHS, REACH
- Surface roughness: Ra ≤0.8 μm (internal)
- Permeability: ≤30 mg/(m²·24h) @23℃, 50% RH
Premium flexible pneumatic tubing with exceptional chemical resistance and anti-aging properties. Features smooth inner walls for optimized airflow, UV-stabilized for occasional outdoor use. The spiral reinforcement structure prevents collapse under vacuum conditions (-0.95 bar). Compatible with ISO 1874 standards for nylon tubing.
- Pneumatic control systems in CNC machinery
- Food processing equipment (FDA compliant version)
- Medical device pneumatic connections
- Automated packaging line air supply
- Laboratory analytical instrument gas lines
- 3D printer compressed air delivery systems
Installation guidance:
Cut with tubing cutter at 90° angle. For secure connections,
insert fully into push-to-connect fittings until "double-click" is heard.
Avoid prolonged exposure to ester-based lubricants. Store coils vertically
in dry conditions below 40℃.
| Property | Property Value |
|---|---|
| sku | PA6040025200MR |
| Inner Diameter | <2.5 mm> |
| Wall Thickness | <0.75 mm> |
| Outer Diameter | 4.0mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | 30mm |
| Length per Roll | 200mm |
| Color Code | Red |
