Airtac PA Nylon Tube PA6040025200MWH
$76.73
Regular price
$84.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PA6040025200MWH
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. PA12 and PA6 nylon tubing excel in high-pressure environments with superior mechanical properties.
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
Maintenance advisory:
Use tube cutters for clean perpendicular cuts. When installing push-to-connect fittings,
insert until hearing an audible click (minimum insertion depth 15mm). Avoid exposure to
ester-based lubricants which may cause polymer degradation.
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA Nylon Tubing PA6040025200MWH Technical Details
- Full model code: PA6040025200MWH
- Material: Polyamide 12 (PA12) reinforced nylon
- Inner diameter: 6.0 mm ±0.1mm
- Outer diameter: 10.0 mm ±0.2mm
- Standard length: 25 meters/roll (200 in model code indicates 25m)
- Color code: MWH (Milky White High Visibility)
- Operating temperature: -40℃ to +80℃ (short peaks to 110℃)
- Max working pressure: 12 bar at 23℃ (reduces to 8 bar at 80℃)
- Burst pressure: ≥35 bar
- Bend radius: 40mm minimum (cold state)
- Weight: 0.5kg ±5% (entire coil)
- Coil dimensions: 300mm(W) × 300mm(D) × 150mm(H)
- Certifications: RoHS compliant, FDA 21 CFR 177.1500
- Surface roughness: Ra ≤1.6μm (internal bore)
High-flex industrial-grade nylon tubing with spiral reinforcement, featuring exceptional kink resistance and memory retention. The semi-translucent white coloration enables visual flow monitoring. Contains UV stabilizers for limited outdoor use (max 6 months direct exposure).
Installation Scenarios:
- Pneumatic valve actuators in automated assembly lines
- Coolant air supply for CNC machining centers
- Vacuum material handling systems
- Food-grade air transfer (dry applications only)
- 3D printer pneumatic extruder connections
Maintenance advisory:
Use tube cutters for clean perpendicular cuts. When installing push-to-connect fittings,
insert until hearing an audible click (minimum insertion depth 15mm). Avoid exposure to
ester-based lubricants which may cause polymer degradation.
Compatible Media:
Dry air, inert gases, mild hydraulic oils (ISO VG32-68), water-glycol mixtures (＜40% concentration)
| Property | Property Value |
|---|---|
| sku | PA6040025200MWH |
| Inner Diameter | <2.5 mm> |
| Wall Thickness | <0.75 mm> |
| Outer Diameter | 4.0mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | 30mm |
| Length per Roll | 200mm |
| Color Code | White |
