Airtac PA Nylon Tube PA6060040100MR
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA6060040100MR Nylon Tubing Specifications
- Model: PA6060040100MR
- Material: Polyamide 12 (PA12) reinforced nylon
- Color: Standard blue with black stripes
- Inner Diameter: 4.0 mm ±0.1 mm
- Outer Diameter: 6.0 mm ±0.15 mm
- Wall Thickness: 1.0 mm nominal
- Operating Pressure: 0.3-1.0 MPa (3-10 bar)
- Burst Pressure: ≥3.0 MPa (30 bar)
- Temperature Range: -40℃ to +80℃ (short-term peak 100℃)
- Minimum Bending Radius: 20 mm (at 20℃)
- Weight: 0.085 kg/m (100m coil: ~8.5 kg)
- Coil Dimensions: 400mm (W) × 400mm (H) × 100mm (D)
- Surface Resistance: 10^12-10^14 Ω (anti-static version available)
- Certifications: RoHS compliant, REACH SVHC-free
Multi-layer extruded pneumatic tubing with spiral reinforcement for kink resistance. Features UV stabilization for outdoor use and mineral oil-resistant formulation. The striped surface pattern enables quick visual circuit identification in complex systems. Compatible with push-to-connect fittings up to 10 bar.
- CNC machine tool pneumatic circuits
- Packaging line air supply networks
- Automated assembly system actuators
- Food processing equipment (FDA-compliant version PA6060040100MR-F)
- Laboratory instrument air lines
Installation guidance:
Cut perpendicularly using tube cutter (not scissors). Insert fully into fittings until
"click" engagement. Avoid continuous exposure to hydraulic fluids. Maximum permissible
axial load: 15N at 20℃. Replace every 5 years in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | PA6060040100MR |
| Inner Diameter | 4.00 mm |
| Wall Thickness | 1.00mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | <45mm> |
| Length per Roll | Stroke 100mm |
| Color Code | Red |
