Airtac PA Nylon Tube PA6060040100MWH
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA6060040100MWH Nylon Tubing Technical Details
- Full model code: PA6060040100MWH
- Material: Nylon 12 (PA12) reinforced
- Inner diameter: 6.0 mm ±0.1mm
- Outer diameter: 10.0 mm ±0.2mm
- Wall thickness: 2.0 mm nominal
- Working pressure: 0.8 MPa (8 bar) at 23℃
- Burst pressure: ≥4.0 MPa
- Temperature range: -40℃ to +80℃ (short-term +120℃)
- Minimum bend radius: 30mm (cold state)
- Color: Natural white (MWH code)
- Weight per meter: 0.108 kg/m ±3%
- Standard coil length: 100 meters
- Coil dimensions: 400mm (W) × 400mm (D) × 200mm (H)
- Certification: RoHS compliant, UL 94 V-2 flame rated
- Surface finish: Smooth bore, low-friction interior
High-flex industrial-grade nylon tubing with exceptional kink resistance and memory retention. Features UV stabilization for outdoor compatibility and mineral oil-resistant formulation. The semi-transparent wall allows visual flow monitoring while maintaining 85% light opacity for contamination detection.
- Pneumatic cylinder connections in automated assembly lines
- Compressed air distribution in CNC machinery
- Vacuum system plumbing for packaging equipment
- Coolant line routing in food processing systems
- Hydraulic control circuits (low-pressure applications)
Installation guidance:
Cut with tube cutter at 90° angle, deburr edges thoroughly.
For push-to-connect fittings, insert until 5mm protrusion remains.
Avoid continuous exposure to ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | PA6060040100MWH |
| Inner Diameter | 4.00 mm |
| Wall Thickness | 1.00mm |
| Outer Diameter | <6.0mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | <45mm> |
| Length per Roll | Stroke 100mm |
| Color Code | White |
