Airtac PA Nylon Tube PA6080060100MBK
2. Available in multiple color options for enhanced system identification and customization.
3. Exhibits excellent dimensional stability and low gas permeability for reliable performance.
4. Outstanding aging resistance, oil resistance, and broad temperature range (-40°C to +120°C) enable versatile industrial applications.
Category: PA Tubing | Brand: AirTAC | Series: PA
AirTAC PA6080060100MBK Nylon Tubing Specifications
- Model: PA6080060100MBK
- Material: PA12 (Polyamide 12) with UV stabilizers
- Inner Diameter: 6 mm ±0.2 mm
- Outer Diameter: 8 mm ±0.3 mm
- Wall Thickness: 1.0 mm ±0.1 mm
- Working Pressure: 0.8 MPa (max 1.2 MPa burst pressure)
- Temperature Range: -40℃ to +80℃ (short-term 100℃ for 1 hour)
- Bending Radius: ≥40 mm (cold state)
- Color: MBK (Matte Black)
- Certification: RoHS compliant, FDA-approved for food zone contact
- Standard Length: 100 meters/roll
- Weight: 2.4 kg/roll (±5%)
- Package Dimensions: 220 mm (Dia.) × 120 mm (W) × 120 mm (H)
- Surface Roughness: Ra ≤1.6 μm (internal)
- Permeability: ≤20 mg/(m²·day) @ 23℃, 50% RH
High-flexibility nylon tubing with anti-kink design, featuring excellent abrasion resistance and chemical stability against oils and weak acids. The matte black finish provides UV protection for outdoor applications. Low moisture absorption (≤2.5% @ 23℃) ensures consistent performance in humid environments.
- Pneumatic tool air supply lines in automotive workshops
- Coolant transfer in CNC machining centers
- Vacuum gripper systems for robotic automation
- Beverage dispensing systems (FDA-compliant version)
- Compressed air networks in semiconductor cleanrooms
Installation note:
Use tube cutters for clean perpendicular cuts. When connecting to push-to-fit fittings,
insert tubing until it bottoms out and give a 1/4 turn twist for secure sealing.
Avoid exposure to chlorinated solvents and direct sunlight exceeding 500W/m² irradiance.
| Property | Property Value |
|---|---|
| sku | PA6080060100MBK |
| Inner Diameter | <6.00 mm> |
| Wall Thickness | 1.00mm |
| Outer Diameter | 8.0MM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (°C): -10 to 70 |
| Bend Radius | 65mm |
| Length per Roll | Stroke 100mm |
| Color Code | Black |
