AirTAC PA6080060100MGN Nylon Tubing Specifications

• Model: PA6080060100MGN
• Material: Polyamide (PA12) with fiber reinforcement
• Inner diameter: 6.0 mm ±0.2 mm
• Outer diameter: 8.0 mm ±0.3 mm
• Standard length: 6100 mm (coiled)
• Working pressure: 0.3-1.2 MPa (43-174 psi)
• Burst pressure: ≥3.6 MPa (522 psi)
• Temperature range: -40℃ to 80℃ (instantaneous peak 100℃)
• Minimum bending radius: 30 mm (cold state)
• Weight: 0.085 kg/m (total ~0.52 kg per coil)
• Color code: MGN (Medium Gray with Navy stripe)
• Certification: ISO 11439, RoHS compliant
• Packaging dimensions: 300mm(W) × 300mm(D) × 300mm(H)

High-flexibility nylon tubing with spiral reinforcement, engineered for compressed air systems requiring kink resistance and precise airflow control. Features UV-resistant additives and anti-static treatment. The internal smooth bore minimizes pressure drop (ΔP ≤0.01 MPa/m at 0.6 MPa).

Typical Applications:

• Pneumatic tool manifolds in automotive assembly
• Dust extraction systems for CNC machines
• Medical device pneumatic circuits
• Food processing equipment (FDA-compliant version available)
• 3D printer air-assisted cooling systems

Installation tip: Use tube cutters for clean perpendicular cuts. When inserting into push-to-connect fittings, push until feeling two distinct "clicks" for leak-proof sealing. Avoid exposure to ketone-based solvents.

Storage note: Store coils horizontally on flat pallets. Maximum stacking height: 5 coils. Protect from direct sunlight during long-term storage.
