Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD6X10 is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø6mm bore, 10mm stroke.
- BoreØ6 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM5×0.8
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10
The AirTAC PBD6X10 is a double-acting, double-rod pen-size mini cylinder with a 6 mm bore and 10 mm stroke. A 3 mm stainless piston rod protrudes from both covers on a single piston. Because both chambers act on the same rod-side annular area, it delivers exactly 10.6 N of push and pull force at 0.5 MPa. This equal force is ideal for symmetric duty where a single-rod cylinder would be weaker on the return stroke.
The twin rods share one piston to resist twist better than a single rod, though you should still use a guided cylinder for zero rotation or lateral loads. The second rod end carries a sensor flag, external stop or second tool without extra hardware. The slim SUS304 stainless body saves space on light end-of-arm tooling. It uses an M5x0.8 air port and a fixed TPU bumper at each end that decelerates the last few mm of travel.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10 Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10 |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm (both ends) |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø6mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10.6 N | 10.6 N |
| 0.7 MPa (max) | 14.8 N | 14.8 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10 Is Used
Dual-Side Transfer
Moves small electronic parts equally well in both directions. The twin rods provide a spare end to mount a second pickup nozzle for a compact shuttle system.
Symmetric Clamp
Clamps a delicate workpiece with identical 10.6 N force on both the extend and retract strokes. The equal push and pull prevents asymmetric part deformation.
Sensor-Flagged Index
Uses the second 3 mm rod end to trip an external mechanical flag. The anti-twist twin rods keep the flag aligned without needing a separate precision guide.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10 the Right Cylinder?
Select this 6 mm bore, 10 mm stroke model when you need symmetric force in a tiny footprint. If your pull-dominant task needs less force, there is no smaller PBD bore, so you must restrict the air pressure. If you need more power, stepping up to the 10 mm bore yields 33.0 N at 0.5 MPa. Remember that both ends need rod clearance across the full 10 mm stroke. Confirm your ordering essentials: bore, stroke, magnet (none here), and mount. The M5x0.8 port and M5x0.8 rod-end thread are fixed for this bore.
The thin 3 mm rod is built for coaxial thrust, not side load. Over long strokes or off-axis loads, add an external guide or linear bearing. The fixed TPU bumper only decelerates the final few mm. With real tooling mass above mid speed, it bottoms out, so meter-out the exhaust or fit an external shock absorber. This plain cylinder does not hold position on air loss; the piston drifts, so use an external stop for a fail-safe hold.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X10 FAQ
The push and pull forces are equal because both chambers act on the same rod-side area. It generates 10.6 N at 0.5 MPa and 14.8 N at the maximum operating pressure of 0.7 MPa.
Yes. The spare rod end carries a sensor flag, external stop or second tool without extra hardware. The twin 3 mm rods also resist rotation better than a single rod, though a guided cylinder is still required for zero rotation or lateral loads.
