Airtac PBD Pen-shaped Double Rod Cylinder PBD6X30S
1. Compliant with JIS (Japanese Industrial Standards) specifications
2. Miniaturized compact design featuring high structural integrity with reduced footprint and lightweight construction
3. Precision-guided piston rod with maintenance-free bearing lubrication system
4. Front-end mounting for PB4/PB6 models; universal front/rear mounting capability for PB10/PB12/PB16 variants
5. Corrosion-resistant stainless steel piston rod and barrel for enhanced durability in mildly corrosive environments
6. Comprehensive product portfolio with multiple configurations and compatible mounting accessories
7. Optimized for high-frequency operations through reduced bore diameter and rapid response characteristics
Category: Double-Rod Cylinders | Brand: AirTAC | Series: PBD
AirTAC PBD6X30S Pen-Style Double Rod Cylinder Specifications
- Model: PBD6X30S
- Bore size: 6mm
- Stroke: 30mm
- Operation type: Double-acting
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber (oil-resistant)
- Cushioning: Adjustable elastic buffer
- Mounting type: Standard (no base mount)
- Port size: M5x0.8 (push-in fitting)
- Weight: 95g ±2g
- Dimensions: 38mm(W) × 30mm(H) × 82mm(L)
- Rod diameter: 2.5mm (both ends)
- Protection class: IP54
- Lubrication: Pre-lubricated (DOP mist compatible)
Ultra-compact dual-rod cylinder with symmetrical force output, featuring precision-ground rods and anti-rotation design. Optimized for bidirectional load applications requiring synchronized linear motion. Includes integrated magnetic sensor slots (G1/8" thread) for position feedback devices.
- Precision alignment mechanisms in semiconductor handlers
- Clamping fixtures for micro-machining centers
- Valve actuation in portable medical analyzers
- Z-axis positioning in 3D printing extruders
- Optical lens adjustment systems
Installation note:
Maintain parallel alignment of both rods during assembly.
Recommended air filtration: 5μm with auto-drain.
For vertical mounting, use auxiliary rod end supports beyond 500mm/s speeds.
| Property | Property Value |
|---|---|
| sku | PBD6X30S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
| Stroke | 30mm |
