Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD6X5 is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø6mm bore, 5mm stroke.
- BoreØ6 mm
- Stroke5 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM5×0.8
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5
The AirTAC PBD6X5 is a double-acting, double-rod pen-size mini cylinder with a 6 mm bore and 5 mm stroke. A piston rod protrudes from both covers, meaning both chambers act on the same rod-side annular area. This geometry delivers exactly 10.6 N of push and pull force at 0.5 MPa.
The twin rods share one piston to resist twist better than a single rod, while providing a spare end for a sensor flag or second tool. Built with SUS304 stainless steel and a slim body, it saves space in tight jigs. It uses an M5x0.8 air port, features an M5x0.8 rod-end thread, and has a fixed TPU bumper at each end.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5 Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5 |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm (both ends) |
| Stroke | 5 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø6mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10.6 N | 10.6 N |
| 0.7 MPa (max) | 14.8 N | 14.8 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×5 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5 Is Used
Dual-Side Transfer
Uses the equal push and pull to push a part out on one side while pulling an empty fixture back on the other, keeping cycle forces symmetric.
Symmetric Micro-Clamp
Clamps a delicate component from both ends simultaneously. The twin rods resist rotation, keeping the jaws aligned within a compact jig.
Sensor-Flagged Index
Uses the spare rod end to push a mechanical flag outward, triggering an external sensor without adding extra hardware to the primary tool.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5 the Right Cylinder?
For this 6 mm bore, the theoretical force is 10.6 N at 0.5 MPa and 14.8 N at 0.7 MPa in both directions. If your duty cycle needs less than 6 N of actual work, this model fits perfectly. If you need more force, stepping up to the 10 mm bore yields 33.0 N at 0.5 MPa. Remember that both ends require rod clearance across the full 5 mm travel. When ordering, confirm the bore, stroke, and mounting choice (LB or FA), as this unit lacks a sensor magnet.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X5 FAQ
It provides equal push and pull forces of 10.6 N at 0.5 MPa and 14.8 N at the maximum operating pressure of 0.7 MPa.
The twin rods on a single piston resist twist better than a single rod and provide a spare end to mount a stop or second tool. Note the thin 3 mm rod is for coaxial thrust, so add an external guide for off-axis loads.
