Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD6X60S is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø6mm bore, 60mm stroke.
- BoreØ6 mm
- Stroke60 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM5×0.8
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S
The AirTAC PBD6X60S is a double-acting, double-rod pen-size mini cylinder with a 6 mm bore and 60 mm stroke. A rod exits both covers on one piston, meaning both chambers act on the same rod-side annular area. This geometry yields equal push and pull forces, giving you about 10.6 N of thrust in both directions at 0.5 MPa.
The twin rods resist twist better than a single rod, while the spare end can carry a sensor flag or second tool without extra hardware. Because this 60 mm stroke exceeds the 50 mm standard maximum for this bore, it is a non-standard, made-to-order item. The slim SUS304 stainless body saves space, and the M5x0.8 air port keeps the footprint small. Note the fixed TPU bumper only decelerates the last few mm of travel.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm (both ends) |
| Stroke | 60 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø6mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10.6 N | 10.6 N |
| 0.7 MPa (max) | 14.8 N | 14.8 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×60 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S Is Used
Dual-Side Transfer
Push a part from one belt and pull another simultaneously using both rod ends, leveraging the 10.6 N equal force for symmetric duty.
Sensor-Flagged Index
Mount a flag on the spare rod end to trigger a reed or electronic switch, confirming position without adding external hardware to the tool.
Symmetric Clamp
Clamp a delicate workpiece from both sides; the twin rods resist rotation, keeping the tooling aligned through the full 60 mm travel.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S the Right Cylinder?
Selecting this double-rod model means sizing both ways: the 6 mm bore provides 10.6 N of force at 0.5 MPa, whereas stepping up to a 10 mm bore yields 33.0 N. If your application needs less than 10.6 N, a smaller alternative must be confirmed from the datasheet. Because both ends have rods, you must layout clearance for the protruding steel across the full 60 mm stroke. Confirm your ordering essentials: 6 mm bore, 60 mm non-standard stroke, S magnet, and mount.
The Ø3 mm rod is slender and built for coaxial thrust, so over this extended 60 mm stroke you should add an external linear bearing to prevent side-load damage.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X60S FAQ
The PBD6X60S provides equal push and pull forces of 10.6 N at 0.5 MPa and 14.8 N at 0.7 MPa. The maximum operating pressure is 0.7 MPa.
Yes, the S denotes a built-in piston magnet that works with AirTAC reed or electronic switches. The spare rod end provides an ideal place to mount a flag for these sensors.
