Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-100S
$28.34
Regular price
$35.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PBJ10X100-100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Compliant with JIS (Japanese Industrial Standards)
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
Installation Tips:
1. Use M3 screws (max torque 0.6N·m) for side mounting
2. Maintain 0.5-1mm play during alignment to prevent binding
3. Lubricate with ISO VG32 turbine oil (non-detergent)
4. For vertical mounting: Add 10% pressure compensation
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
AirTAC PBJ Adjustable Pen Cylinder PBJ10X100-100S Technical Details
- Model Code Breakdown: PBJ10-X100-100S
- PBJ: Pen-type adjustable cylinder series
- 10: 10mm bore diameter
- X100: 100mm standard stroke
- 100S: 100mm adjustable stroke range
- Operating Pressure: 0.1-0.9 MPa (14.5-130.5 PSI)
- Cushioning: Adjustable rubber bumper (both ends)
- Port Size: M5x0.8 (Dual ports with G1/8 adapter optional)
- Piston Material: Anodized aluminum alloy
- Rod Material: Stainless steel SUS304
- Seals: Heat-resistant NBR (Nitrile) up to 90℃
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 0.28 kg (with standard fittings)
- Dimensions:
- Body Diameter: Φ16mm
- Retracted Length: 121mm
- Extended Length: 221mm (base to rod end)
- Mounting Bracket: 25mm x 18mm
- Repeat Accuracy: ±0.1mm
- IP Rating: IP54 (standard), IP67 with optional wiper
Ultra-slim pneumatic actuator featuring 360° adjustable stroke via rotating end cap. Precision-ground rod with chrome plating resists side loads. Integrated shock absorption prevents chatter in high-cycle applications (up to 5Hz). Compatible with vacuum pick-up systems when paired with suction cups.
Ideal for Space-Constrained Automation:
- PCB component insertion machines
- Dispenser valve actuation in pharmaceutical packaging
- Micro-part sorting gates
- Cleanroom wafer handling robots
- Textile thread tensioning mechanisms
Installation Tips:1. Use M3 screws (max torque 0.6N·m) for side mounting
2. Maintain 0.5-1mm play during alignment to prevent binding
3. Lubricate with ISO VG32 turbine oil (non-detergent)
4. For vertical mounting: Add 10% pressure compensation
| Property | Property Value |
|---|---|
| sku | PBJ10X100-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 100mm |
