Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-40
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
AirTAC PBJ Adjustable Pen-Type Cylinder PBJ10X100-40 Specifications
- Model: PBJ10X100-40
- Type: Adjustable stroke pen cylinder (double-acting)
- Bore size: 10mm
- Stroke: 100mm (adjustable via mechanical stopper)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Front flange with through-hole (M4x0.7)
- Port size: M5x0.8 (Rc1/8 optional)
- Material: Aluminum alloy barrel, hardened stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.28kg
- Dimensions: 20mm (Ø) × 130mm (L) × 30mm (H) (flange height)
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500mm/s
- Air consumption: 7.85cm³/stroke @ 0.5MPa
Ultra-compact cylinder with micrometer-style stroke adjustment (external screw mechanism), featuring a space-saving design 35% smaller than standard cylinders. Integrated mounting flange allows direct installation in confined spaces. Gold-anodized piston rod resists corrosion in humid environments.
- Precision part positioning in semiconductor handling robots
- Micro-dosing valve actuation in medical devices
- Paper feed mechanisms in compact printers
- Lens adjustment systems in optical equipment
- Clamping fixtures for PCB assembly
Installation note:
Lubricate piston rod weekly with ISO VG32 hydraulic oil. For vertical mounting,
use speed controller to prevent free-fall. Max lateral load: 3N.
Adjust stroke while depressurized.
| Property | Property Value |
|---|---|
| sku | PBJ10X100-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 100mm |
