Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X125-100
$28.34
Regular price
$35.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PBJ10X125-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Compliant with JIS (Japanese Industrial Standards)
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
Operation guidance:
Adjust stroke by loosening locknut and rotating stopper (1 full rotation = 1.5mm adjustment).
Lubricate rod every 500km travel distance using ISO VG32 hydraulic oil. Avoid side loads exceeding 2N.
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
AirTAC PBJ Adjustable Pen Cylinder PBJ10X125-100 Specifications
- Model: PBJ10X125-100
- Type: Adjustable stroke pen-type cylinder (double acting)
- Bore size: 10mm (PBJ series standard)
- Stroke: 125mm (maximum) with 100mm adjustable range
- Stroke adjustment: Mechanical stopper with locknut
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports at both ends)
- Cushioning: Adjustable pneumatic cushion
- Mounting: Front flange (standard), optional side mounts
- Material: Aluminum alloy barrel, hard anodized piston rod
- Weight: 310g ±5% (without accessories)
- Dimensions:
- Total length (extended): 175mm
- Barrel diameter: 16mm
- Mounting base: 30mm × 12mm (L×W)
- Rod end thread: M6×1.0
Ultra-compact linear actuator with precision stroke adjustment, featuring a 360° rotatable piston rod end for flexible installation. The through-rod design allows external position detection. Includes wear-resistant guide bushings and IP54 protection against particulate ingress.
Typical Applications:
- PCB component insertion machines
- Medical device positioning mechanisms
- Precision clamping in semiconductor handling
- Automated test equipment actuators
- Textile machinery thread control
Operation guidance:
Adjust stroke by loosening locknut and rotating stopper (1 full rotation = 1.5mm adjustment).
Lubricate rod every 500km travel distance using ISO VG32 hydraulic oil. Avoid side loads exceeding 2N.
| Property | Property Value |
|---|---|
| sku | PBJ10X125-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 125mm |
