Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X125-20
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
AirTAC PBJ Adjustable Pen-Type Cylinder PBJ10X125-20 Technical Details
- Model Code: PBJ10X125-20
- Type: Double-acting cylinder with adjustable cushioning
- Bore size: 10mm (0.39")
- Stroke: 125mm (4.92")
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Piston speed: 50–800 mm/s (air cushion adjusted)
- Ambient temperature: -10℃ to 70℃ (14°F to 158°F)
- Port thread: M5x0.8 (standard) / NPT1/8 optional
- Rod end: Double-ended threaded rod (M5x0.8)
- Cushion type: External adjustable rubber buffers
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.28kg (0.62 lbs)
- Dimensions: 160mm(L) × 28mm(W) × 28mm(H) (6.3"×1.1"×1.1")
- Mounting: Standard foot mounting (MF1) with 25mm hole spacing
- ISO compatibility: Compliant with ISO 6432:2015
Ultra-slim pneumatic cylinder optimized for precision linear motion in confined spaces. Features dual-position cushion adjustment screws for smooth deceleration and reduced end-impact noise. The chrome-plated piston rod includes scratch-resistant coating (3-5μm thickness) for extended seal life. Requires filtered air (5-50μm) with ISO VG32 turbine oil mist lubrication.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Semiconductor wafer handling robots
- Optical lens polishing equipment
- Desktop CNC tool changers
Installation tips:
(1) Align cylinder axis within ±0.5° of load direction.
(2) Apply thread locker (Loctite 243 recommended) on mounting screws.
(3) Allow 2-3mm clearance behind cushion screws for adjustment.
(4) Lubricate every 3 million cycles under normal operation.
| Property | Property Value |
|---|---|
| sku | PBJ10X125-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 125mm |
