Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X125-30
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
AirTAC PBJ10X125-30 Adjustable Pen-Style Cylinder Specifications
- Model: PBJ10X125-30
- Type: Adjustable stroke pen-type pneumatic cylinder
- Bore size: 10mm (0.39")
- Stroke: 125mm ±0.5mm (4.92")
- Operating pressure: 0.05-0.9 MPa (7-130 PSI)
- Medium temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting: Front threaded mounting (M10x1.25)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Piston rod thread: M6x1.0 external thread
- Tube material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seals: NBR (nitrile) wear-resistant compound
- Weight: 310g ±5g (0.68 lbs)
- Dimensions:
- Total length: 199mm (7.83")
- Body diameter: 20mm (0.79")
- Mounting flange width: 30mm (1.18")
- Max theoretical thrust: 70.7N @0.9MPa
- ISO standard: 6432 (8mm-25mm bore series)
A precision miniaturized actuator featuring dual adjustable stroke limiters with 360° rotatable auto-stop nuts. The chromium-plated piston rod integrates dust-resistant scraper seals, while the multi-lip rod seal ensures leak-free operation. Requires 40μm filtered air with ISO VG32 hydraulic oil mist lubrication (optional oil-free operation).
- PCB board clamping in SMT machines
- Lens positioning systems for optical inspection
- Precision dosing valves in pharmaceutical equipment
- Robotic end-effector tool changers
- Semiconductor wafer handling robots
Installation guidelines:
Maintain ≤0.05mm perpendicularity between rod axis and load direction.
For vertical mounting, use counterbalance valves when handling suspended loads.
Stroke adjustment requires 2mm minimum residual cushion length.
| Property | Property Value |
|---|---|
| sku | PBJ10X125-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 125mm |
