Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X125-30S
$29.74
Regular price
$37.24
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PBJ10X125-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Compliant with JIS (Japanese Industrial Standards)
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
Installation tip:
For optimal performance, align cylinder axis within 0.2mm perpendicularity tolerance.
Use thread locker on adjustment screw after calibration. Maximum side load: 3N.
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
AirTAC PBJ Adjustable Pen-Type Cylinder PBJ10X125-30S Specifications
- Model: PBJ10X125-30S
- Type: Adjustable stroke pen cylinder (double-acting)
- Bore size: 10mm
- Stroke: 125mm (±0.5mm tolerance)
- Adjustment range: 0-30mm continuous stroke adjustment
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (1/8" NPT optional)
- Cushioning: Adjustable rubber bumper
- Mounting: Side mounting holes (2x Ø4.5mm) with 25mm spacing
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 420g ±5% (without accessories)
- Dimensions: 160mm(L) × 25mm(W) × 25mm(H) (fully retracted)
- Rod thread: M6x1.0 external thread at front end
- Max speed: 500mm/s (with cushion engaged)
- Lubrication: Pre-lubricated (Grease-free operation available)
Ultra-compact linear actuator with micrometer-style stroke adjustment, featuring a 360° rotatable locknut for precise positioning. The anodized body provides corrosion resistance, while the double-sealed piston rod wiper ensures debris protection. Includes built-in magnetic sensor slots (G1/8" tap) for position feedback devices.
Typical Applications:
- Precision clamping in PCB assembly fixtures
- Micro-dosing mechanisms in pharmaceutical equipment
- Z-axis adjustment in 3D printing/pick-and-place machines
- Valve actuation in compact fluid control systems
- Optical component positioning in laser alignment setups
Installation tip:
For optimal performance, align cylinder axis within 0.2mm perpendicularity tolerance.
Use thread locker on adjustment screw after calibration. Maximum side load: 3N.
Adjustment procedure:
- Loosen locknut (30mm adjustment range marked on rod)
- Rotate piston rod: CW to shorten stroke, CCW to extend
- Re-tighten locknut to 0.7-0.9Nm torque
- Verify stroke with test cycles before operation
| Property | Property Value |
|---|---|
| sku | PBJ10X125-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 125mm |
