Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X125-50
2、Miniature design featuring compact structure, small footprint, and lightweight construction
3、High-precision piston rod guidance with self-lubricating guide bearings (maintenance-free lubrication)
4、PB4 & PB6 models support front-end mounting only; PB10, PB12, and PB16 allow both-end mounting configurations
5、Stainless steel piston rod and cylinder barrel construction for enhanced corrosion resistance in harsh environments
6、Comprehensive range of cylinder specifications and mounting accessories for flexible system integration
7、Optimized for high-frequency operation with reduced bore size and rapid response characteristics
Category: Pen Cylinders | Brand: AIRTAC | Series: PBJ Adjustable Pen Cylinder
AirTAC PBJ10X125-50 Adjustable Pen Cylinder Specifications
- Model: PBJ10X125-50
- Type: Double-acting adjustable stroke pen cylinder
- Bore size: 10mm
- Stroke: 125mm (±5mm adjustable)
- Adjustment range: ±5° angle adjustment at rod end
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5×0.8 (standard) with NPT1/8 adapter option
- Buffer type: Elastic cushioning with position-lock mechanism
- Mounting style: Basic rod-end threaded (M10×1.25)
- Cylinder tube material: Anodized aluminum alloy
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 380g ±5% (including mounting accessories)
- Dimensions:
- Extended length: 196mm
- Retracted length: 71mm
- Body diameter: Φ22mm
- Mounting base width: 28mm
Ultra-compact linear actuator featuring micrometer-style stroke adjustment (50 divisions with 0.1mm/division precision). Integrated shock absorption prevents position drift during high-cycle operations. The rotation-lock collar enables ±5° angular alignment compensation. Corrosion-resistant construction with IP54 splash protection.
- Precision wafer handling in semiconductor FOUP loaders
- Micro-dispensing systems for medical device assembly
- PCB test probe positioning mechanisms
- Optical lens alignment in camera module production
- Miniature part ejection in micro-molding machines
Operation guidance:
Adjust stroke via hex wrench on the graduated collar while pressurized.
Lubricate through the rod-end grease nipple (ISO VG32) every 500,000 cycles.
Avoid side loads exceeding 3N to maintain alignment accuracy.
| Property | Property Value |
|---|---|
| sku | PBJ10X125-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | 125mm |
