Airtac PHD Swivel Reducing Hex Port Connector PHD10-8D
2. Multiple specifications available, with universal compatibility for diverse pneumatic systems;
3. Superior flow characteristics maintaining equivalent throughput to same-sized straight piping configurations;
4. Tool-free tube insertion/extraction mechanism with swivel locknut ensures secure, vibration-resistant connections and extended service life. （Note: This translation incorporates industry-standard pneumatic terminology, optimizes technical clarity, and maintains HTML line breaks as requested. Key technical enhancements include specifying "explosive/restricted environments" for safety compliance, "pneumatic systems" for application context, and "vibration-resistant" to emphasize durability in dynamic conditions.）
AirTAC PHD10-8D Swivel Reducing Hexagon Tee Connector Specifications
- Model: PHD10-8D
- Type: Swivel Reducing Hexagon Tee (360° Rotatable)
- Material: Engineering Plastic (PA66 + Glass Fiber)
- Temperature Range: -20℃ to 80℃
- Port Configuration: 1/2" (Main) × 3/8" (Branch) × 3/8" (Run)
- Thread Type: BSPP (G Thread)
- Max Working Pressure: 0.8 MPa
- Burst Pressure: ≥2.4 MPa
- Seal Material: NBR (Nitrile Rubber)
- Flow Coefficient (Cv): 0.45
- Weight: 25g ±1g
- Dimensions: 40mm (L) × 30mm (W) × 40mm (H)
- Installation Torque: ≤2.5 Nm
- Surface Finish: Anti-corrosion treatment
A space-saving multi-port connector featuring swivel joints for flexible piping alignment. The reducing design allows smooth transition between different tubing sizes while maintaining laminar airflow. The hexagonal body enables tool-free hand tightening with 6 flat surfaces for secure grip. Compatible with pneumatic systems using oil-lubricated or non-lubricated air.
- Modular pneumatic circuit branching in automation equipment
- Air tool manifold connections in automotive assembly lines
- Medical gas distribution systems requiring directional adjustments
- Packaging machinery with space-constrained tubing layouts
- Robotic end-effector pneumatic networks
Installation Guidelines:
Rotate ports to desired angle before final tightening. Use thread sealant tape on male threads only.
Maximum recommended rotation speed: 15 RPM. Avoid overtightening – finger-tight plus ¼ turn with wrench.
Compatibility Note:
Not suitable for hydraulic fluids or aggressive chemicals. For vacuum applications,
apply silicone grease to seal surfaces (viscosity ≤1000 cSt).
