Airtac PHW F Thread Swivel Tee Fitting PHW1204D-S
AirTAC PHW Series F-Type Swivel Tee Fitting PHW1204D-S Specifications
- Model: PHW1204D-S
- Type: F-Type (Female Thread) 360° Rotatable Tee Connector
- Thread Standard: BSPP (Parallel Thread)
- Thread Size: PT1/4 (G1/4 Equivalent)
- Material: Lead-Free Brass (C37700) with Electroless Nickel Plating
- Seal Type: EPDM O-ring (Standard) / Optional NBR or FKM
- Operating Pressure: 0.05-1.0 MPa
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -20℃ to 120℃ (Standard Seal)
- Weight: 55g ±2g
- Dimensions: 35mm(L) × 20mm(W) × 20mm(H)
- Surface Roughness: Ra ≤3.2μm (Flow Path)
- Rotational Torque: 0.5-1.2 N·m
- Vibration Resistance: 10-2000Hz, 5G Max
- Corrosion Resistance: 96hrs Neutral Salt Spray Test (NSS)
Precision-engineered tee connector featuring 360° swivel capability for flexible piping alignment in confined spaces. The electroplated finish provides enhanced corrosion resistance against hydraulic fluids and industrial coolants. Optimized flow path design minimizes pressure drop (ΔP ≤0.02MPa @ 0.5MPa).
- Modular pneumatic circuit branching in CNC machines
- Coolant line distribution in semiconductor FOUP systems
- Multi-axis robotic tool changer interfaces
- Vacuum system manifold connections
- Medical gas delivery systems (Oxygen/Nitrogen)
Installation protocol:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Tighten to 12-15 N·m torque using backup wrench on hex flats.
Perform 5 full rotation tests post-installation to verify smooth swivel action.
| Property | Property Value |
|---|---|
| sku | PHW1204D-S |
