Airtac PHW F Thread Swivel Tee Fitting PHW401
AirTAC PHW F-Type Threaded Swivel Tee Connector PHW401 Technical Details
- Model: PHW401
- Type: 360° rotatable tee connector with F-type metric threads
- Port configuration: 1 inlet × 2 outlet (equal distribution)
- Thread standard: M5×0.8 female threads (F-type metric)
- Material: Nickel-plated brass body
- Seal: NBR (Nitrile) O-rings
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (dry air)
- Flow capacity: 200 NL/min @ 0.5 MPa
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 23g ±1g
- Dimensions: 24mm(L) × 18mm(W) × 24mm(H)
- Vibration resistance: ≤49 m/s² (ISO 10816-3)
- Certification: RoHS compliant
Precision-engineered swivel tee connector featuring tool-free 360° rotation adjustment for optimal tubing alignment. The electroplated finish provides corrosion resistance in humid environments. Integrated NBR seals ensure leak-free connections up to 1 MPa. Compatible with PU/Nylon tubing (OD 4mm or 6mm).
- Modular pneumatic circuit branching in factory automation
- Compact instrument air distribution systems
- Robotic end-effector pneumatic networks
- Medical device gas line manifolds
- Semiconductor manufacturing equipment
Installation protocol:
Hand-tighten initially with 1.5-2 N·m torque, then secure with
3/4 additional turn using spanner flats. Avoid overtightening
which may deform NBR seals. Perform pressure test at 1.5×
working pressure after installation.
| Property | Property Value |
|---|---|
| sku | PHW401 |
