Airtac PKD Reducing Thread 5-Way Fitting PKD6-401
AirTAC PKD Series Reducing Thread Five-Way Union PKD6-401 Technical Details
- Model: PKD6-401
- Type: 5-port reducing union with male threads
- Port configuration: 1/8" (G1/8) ×4 ports + 1/4" (G1/4) ×1 port
- Thread standard: ISO 228 (G-series parallel threads)
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Seal material: NBR (Nitrile) rubber
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 28g ±2g
- Dimensions: 40mm(L) × 18mm(W) × 18mm(H)
- Surface roughness: Ra ≤3.2μm
- Proof pressure: 1.5 MPa (217 PSI)
- Flow coefficient (Cv): 0.15
- Compliance: RoHS 2.0 compliant
Precision-machined flow distribution component designed for multi-branch pneumatic circuit connections. Features stepped port sizing (6mm to 10mm equivalent) for system optimization. Anti-vibration design with 360° rotatable ports enables flexible installation orientations. Includes built-in O-ring compression seals requiring no additional thread tape.
- Modular pneumatic control systems requiring flow division
- Multi-axis CNC machine tool air supply distribution
- Packaging line manifold conversions
- Laboratory instrument gas mixing stations
- Automated assembly line tooling circuits
Installation protocol:
Apply 0.3-0.6Nm torque during assembly. Use alignment marks between body and nut for proper sealing.
Compatible with ISO 8434-1/DIN 2353 metric tubing systems. Requires periodic inspection for seal wear every
2,000 operating hours in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | PKD6-401 |
