Airtac PSL Throttle Speed Control Fitting PSL1002A
2、Precisely controls operational speed of pneumatic actuators and pressure signal transmission efficiency;
3、Superior flow characteristics with high sensitivity and precise micro-adjustment capabilities;
4、Exhaust throttle and intake throttle configurations available for compatibility with diverse actuator models;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention;
6、Adjustment lever features an anti-drop structural design;
7、Integrated PT thread adhesive ensures leak-proof sealing at threaded connections;
Category: L-Type Throttle Valve Fittings | Brand: AirTAC | Series: PSL
AirTAC PSL Throttle Speed Control Connector PSL1002A Specifications
- Model: PSL1002A
- Type: One-way throttle speed control valve with check function
- Port size: PT1/8 (G1/8 optional)
- Thread standard: BSPP (parallel thread)
- Body material: Nickel-plated brass
- Seal material: NBR (Nitrile rubber)
- Flow adjustment range: 0.05-5 L/min (air)
- Operating pressure: 0.05-0.8 MPa
- Temperature range: -20℃ to 80℃
- Weight: 52g ±2g
- Dimensions: 32mm(L) × 20mm(W) × 38mm(H)
- Protection rating: IP40
- Flow direction: Bi-directional (arrow indicates recommended installation direction)
Precision throttle valve with integrated check valve for controlled airflow regulation in pneumatic systems. Features micro-adjustment knob with 300° rotation range for fine-tuning, and corrosion-resistant construction with leak-proof O-ring seals. Requires 5μm filtered air for optimal performance.
- Cylinder speed control in automation machinery
- Pneumatic gripper actuation timing adjustment
- Air cushion shock absorber regulation
- Medical equipment pneumatic circuit balancing
- Packaging machine air nozzle flow control
Installation note:
Install with arrow aligned to main flow direction. For exhaust control applications,
pair with reverse-flow check valve. Perform initial calibration at 0.5 MPa pressure.
Lubricate adjustment screw quarterly with ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | PSL1002A |
