Airtac PSL Throttle Speed Control Fitting PSL1002A-S
2、Precisely controls operational speed of pneumatic actuators and pressure signal transmission efficiency;
3、Superior flow characteristics with high sensitivity and precise micro-adjustment capabilities;
4、Exhaust throttle and intake throttle configurations available for compatibility with diverse actuator models;
5、Nickel-plated brass body provides enhanced corrosion resistance and contamination prevention;
6、Adjustment lever features an anti-drop structural design;
7、Integrated PT thread adhesive ensures leak-proof sealing at threaded connections;
Category: L-Type Throttle Valve Fittings | Brand: AirTAC | Series: PSL
AirTAC PSL1002A-S Throttle Speed Control Fitting Specifications
- Model: PSL1002A-S
- Type: Adjustable one-way throttle valve with locking mechanism
- Port size: PT1/8 (G1/8 equivalent)
- Thread specification: Rc1/8 (ISO standard)
- Flow adjustment range: 0.05-5 L/min (air), 0.01-1 L/min (liquid)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Body material: Brass CW617N
- Seal material: HNBR (Hydrogenated Nitrile)
- Knob material: POM (Polyoxymethylene)
- Weight: 23g ±1g
- Dimensions: 32mm(L) × 22mm(W) × 28mm(H)
- Pressure drop: ≤0.02 MPa at max flow
- Repeat accuracy: ±10% of set flow rate
Precision bidirectional flow control valve featuring 270° rotation adjustment with tactile click stops. The chrome-plated brass body ensures corrosion resistance in humid environments. Integrated O-ring groove allows direct manifold mounting. Requires 25μm filtration for optimal performance.
- Pneumatic cylinder speed regulation in automation lines
- Vacuum system flow control
- Medical gas equipment pressure modulation
- Packaging machine actuator timing adjustment
- Semiconductor handling robot end-effector controls
Installation note:
For liquid applications, install vertically with arrow marking facing upward.
Apply 2-3Nm torque during assembly - over-tightening may deform nylon components.
Perform flow calibration after 50 operation cycles.
| Property | Property Value |
|---|---|
| sku | PSL1002A-S |
